Features:

  • Rugged design
  • Smooth performance
  • Highly efficient
  • 2/ years 6000 HRS warranty
  • 5 years / 6000 HRS warranty Optional
  • Doors are gasketed with high quality
    EPDN gaskets to avoid leakage of sound.

VECV

Being one of the reputed organizations, operating in this domain, we are engaged in trading and supplying a quality range of 30 kVA to 160 kVA DG sets powered by Eicher.

Specifications:

  • Compact, Sleek, Manual/Automatic.
  • Sound Proof, Weather Proof enclosure.
  • Confirms to statutory Govt. Noise level norms.
  • Custom/Tailor made design, engineered by a team of experts using modern CAD/CAM techniques.
  • The Enclosure is of modular construction with the provision to assemble and dismantle easily.
  • The Enclosure is fabricated in 16 SWG-CRCA-sheet.
  • The sheet metal components are eight tanks pretreated and is Polyester based powder coated (inside as well as outside) for long life.
  • All Nuts-bolts, hardware are Zinc coated.
  • In-built fuel tank provided with breather, drain plugs for filling & draining diesel from outside the Enclosure.
  • The fuel level is indicated with the help of fuel gauge meter.
  • Drain plugs provided outside the Enclosure for draining mobile oil from outside the end.
  • Battery is provided in a tray inside the Enclosure.
  • Doors are gaskets with high quality EPDM gaskets to avoid leakage of sound.
  • A special Residential silencer is provided to control exhaust noise.
  • Specially designed sound attenuators are provided to control sound at air entry & exit points inside the Enclosure.
  • To make the system vibration free, engine and alternator (Single/Double Bearing) are mounted on specially designed anti-vibration pads mounted on base frame.
  • The enclosure is designed and layout of the equipment is such that there is easy access to all serviceable parts.
  • Adequate ventilation is provided to meet air requirement for combustion & heat removal. For specific engine, if required, a blower is used to meet total air requirement & air changes.
  • There is an arrangement for illumination inside the Enclosure.
  • High water temperatures Low lube oil pressures High enclosure temperatures Emergency stop push button outside the Enclosure
  • Control panel is mounted inside Enclosure itself. All parameters are visible from outside & all push buttons are accessible through a separate door.
  • Engine/Alternator used for maximum Silent DG set carries a warranty for their respective model.
  • Noise level is 75 DB (A) at distance of 1 mtrs. In open environment

DG sets powered by EICHER:

                                                                                            Technical Specification
DG Set Model Unit VE-30 VE-40 VE-45 VE-50 VE-62.5 VE-75 VE-82.5 VE-100 VE-125
Genset Rating KVA 30 40 45 50 62.5 75 82.5 100 125
Power Factor PF 80
Genset Rating kWe 24 32 36 40 50 60 66 80 100
Engine Make (VECV)
Engine Model EE483TCI EE483TCI EE483TCI EE483TCI EE483TCI EE683TCI EE683TCI EE694TCI EE694TCI
No. of Cylinders No. 4 4 4 4 4 6 6 6 6
Nature of Aspiration TCI TCI TCI TCI TCI TCI TCI TCI TCI
Displacement Liters 3.3 3.3 3.3 3.3 3.3 4.95 4.95 5.7 5.7
Compression Ratio 17:01 17:01 17:01 17:01 17:01 17:01 17:01 17.5:01 17.5:01
Bore X Stroke MM 100 x 105 100 x 105 100 x 105 100 x 105 100 x 105 100 x 105 100 x 105 100 X 120 100 X 120
Electric System Volt 12 V DC 12 V DC 12 V DC 12 V DC 12 V DC 12 V DC 12 V DC 12 V DC 12 V DC
Battery AH 88 88 88 88 88 120 120 120 120
Lube Oil Consumption* % F. Cons 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1
Lube Oil System Capacity Liters 11 11 11 11 11 14 14 16 16
BSFC at 75% Load* Gm/HP-Hr 139 139 149 149 149 157 157 156 156
Service Interval Hours/Months 500 Hours/6 Months
Governing Class Mechanical A1
Alternator Make KEC / Mecc Alte / Equivalent make
Alternator Type Brushless
No. of Phase 3 Phase/1 Phase 3 Phase
Frequency Hz 50 Hz
Type of Insulation Class H
Type of Panel Standard Manual Panel (Optional AMF Panel)
Acoustic Enclosure Size* (LxWxH) mm 2500x1050x1500 2800x1050x1500 3200x1150x1500 (3400x1250x1500) (3750x1250x1500)
Fuel Tank Cap.* Liters 150 150 150 150 150 250 250 300 300
Approx DG Set Weight* Kgs 1120 1130 1250 1250 1250 1610 1610 1790 1790

Conditions Apply

(*) Other makes of Alternator can be available on request
Power rating as per standard reference condition as per –BS 5514 / ISO 3046 / ISO 8528 & IS 10002 / ISO 3046
Generator set specifications are subject to change due to continuous product development without prior notice

Standard Scope Of Supply:
Lighting Inside the Acoustic Enclosure Included
Fuel Tank & Fuel Piping Inbuild (Removable Type with Lock & Key Arrangement)
First fill of Lube Oil Included & Coolend
Power Cable Included within Acoustic Enclosure (Netween Alternator & DG Panel)
Silencer with Tail Pipe Included
Fuel Level Gauge & Sensor Included
Emergency Stop Button Included

Exclusion/Optional

Transportation & Transit Insurance

Unloading & Shifting of DG Set at Site

Civil Foundation at Site

Power & Control Cabling outside Acoustic Enclosure

Earthing of Equipment (DG Set & Panel) at Site

Exhaust Pipe Extension

Any kind of Statutory Approval

Warranty : Standard warranty shall be 24 Months from date of supply or 5000 running hours whichever is earlier for manufacturing defect of Equipment.

Optional Extended Warranty is available at extra cost.
