MTU

Commercial generator sets available in a range of sizes to meet any application. Able to start and assume load in less than 10 seconds, and rated load in a single step, Cummins generator sets are the epitome of rugged dependability and reliable mechanical and electrical performance. Our generators are well suited to utility peaking plants, Distributed Generation (DG) facilities, peak shaving (or peak lopping), and power management at large commercial or industrial sites. Cummins Power Generation has fully redesigned its high-range generator sets to deliver the reliability, efficiency and versatility that your customers want.

MTU Gas Generating Sets:

50 Hz/1500 min-1
Model Engine Stand-by(kVA) Prime Code:P (kVA) Prime Code:CP (kVA) Continuouos (kVA)
3.3 kV 6.6 kV 10 kV 11 kV 3.3 kV 6.6 kV 10 kV 11 kV 3.3 kV 6.6 kV 10 kV 11 kV 3.3 kV 6.6 kV 10 kV 11 kV
MGS2700HV 16R2-PTAW 2500 2500 2500 2500 2250 2250 2250  2250  2250 2250  2250  2250 1900  1900 1900 1900
 MGS2500HV  S16R-PTAA2  2250  2250  2250  2250 2010  2010  2010  2005  2000  2000  2000  2000  –  –  –
 MGS2000HV  S16R-PTA2-S  2200  2200  2200  2200  2000  2000  2000  2000 1900  1900  1900  1900  –  –  –  –
 MGS1500HV  S16R-PTA-S  2000  2000  2000  2000  1810  1810 1800  1800 1700  1725  1725  1725 1560  1550  1540  1540
 MGS1400HV  S12R-PTA2-S  1575  1600  1600  1600  1450  1450  1450  1450 1380 1380  1380  1380  –  –  –  –
 MGS2500HV  S12R-PTA-S  1475  1475  1475  1475  1350  1350  1340  1340  1280  1280 1270  1270  1140  1140  1130 1130
 MGS1000HV  S12H-PTA-S  1225  1225  1225  1225  1060  1100  1100 1100  1050  1050  1040  1040  940  945  935  935
